A2A for Beginners, Part 2: Building an Agent from Scratch

In Part 1, we covered the theory of A2A: agent cards, JSON-RPC, tasks, and artifacts. Now we're going to build a small agent by hand so the wire format becomes concrete.

No frameworks. No A2A SDK. Just Python, Flask, and the A2A 0.3.0 spec.

By the end of this post, you'll have:

1. A working unit-conversion agent
2. A client that discovers the agent and talks to it over JSON-RPC
3. A minimal but much more accurate picture of what A2A 0.3.0 actually requires

What We're Building

Our agent will convert between:

• Temperature: Fahrenheit, Celsius, Kelvin
• Distance: miles, kilometers, meters, feet
• Weight: pounds, kilograms, ounces, grams

Why a unit converter? Because the conversion logic is boring, and that's useful. We want to focus on the protocol.

This agent does not use an LLM. That's intentional. A2A standardizes how agents communicate, not how they think. The thing behind the protocol could be GPT, a database, a rules engine, or a handful of arithmetic functions.

Prerequisites

You'll need Python 3.10+.

mkdir a2a-converter && cd a2a-converter
python -m venv venv
source venv/bin/activate  # On Windows: venv\Scripts\activate
pip install flask requests

We'll use Flask because it gives us a small HTTP server with almost no ceremony.

Step 1: The Agent Card

Every A2A agent starts with an agent card. This is the document clients fetch to learn the agent's name, capabilities, and transports.

Create agent_card.py:

AGENT_CARD = {
    "name": "Unit Converter",
    "description": "Converts between common units of measurement including temperature, distance, and weight.",
    "url": "http://localhost:5000",
    "preferredTransport": "JSONRPC",
    "additionalInterfaces": [
        {
            "url": "http://localhost:5000",
            "transport": "JSONRPC",
        }
    ],
    "version": "1.0.0",
    "protocolVersion": "0.3.0",
    "capabilities": {
        "streaming": False,
        "pushNotifications": False
    },
    "defaultInputModes": ["text/plain"],
    "defaultOutputModes": ["text/plain"],
    "skills": [
        {
            "id": "temperature",
            "name": "Temperature Conversion",
            "description": "Convert between Fahrenheit, Celsius, and Kelvin.",
            "tags": ["temperature", "conversion", "units"],
            "examples": [
                "Convert 100 Fahrenheit to Celsius",
                "32°F in Kelvin"
            ]
        },
        {
            "id": "distance",
            "name": "Distance Conversion",
            "description": "Convert between miles, kilometers, meters, and feet.",
            "tags": ["distance", "length", "conversion", "units"],
            "examples": [
                "Convert 5 miles to kilometers",
                "1000 meters in feet"
            ]
        },
        {
            "id": "weight",
            "name": "Weight Conversion",
            "description": "Convert between pounds, kilograms, ounces, and grams.",
            "tags": ["weight", "mass", "conversion", "units"],
            "examples": [
                "Convert 150 pounds to kilograms",
                "250 grams in ounces"
            ]
        }
    ],
    "provider": {
        "organization": "A2A Tutorial"
    }
}

Important fields:

• protocolVersion: "0.3.0" tells clients which A2A schema to expect.
• preferredTransport: "JSONRPC" tells clients which transport to use first.
• url is the primary endpoint for that preferred transport.
• additionalInterfaces lets you declare the transport explicitly.
• streaming: false and pushNotifications: false tell clients we only support synchronous request/response behavior.

You'll often see agent cards served from /.well-known/agent-card.json. That's the recommended well-known discovery convention, and it's the one we'll use here.

Step 2: The Flask Server

Our server needs:

1. GET /.well-known/agent-card.json for discovery
2. A JSON-RPC endpoint at the URL declared in the card

In this tutorial, that endpoint is POST / because the card's url is http://localhost:5000.

Start server.py like this:

import uuid
from copy import deepcopy
from datetime import datetime, timezone

from flask import Flask, jsonify, request

from agent_card import AGENT_CARD
from converter import convert

app = Flask(__name__)
TASKS = {}

TASK_NOT_FOUND = -32001
TASK_NOT_CANCELABLE = -32002
UNSUPPORTED_OPERATION = -32003
CONTENT_TYPE_NOT_SUPPORTED = -32005

TERMINAL_STATES = {"completed", "failed", "canceled", "rejected"}


def utc_now():
    return datetime.now(timezone.utc).isoformat().replace("+00:00", "Z")


def build_message(role, text, context_id, task_id=None):
    message = {
        "kind": "message",
        "messageId": str(uuid.uuid4()),
        "contextId": context_id,
        "role": role,
        "parts": [{"kind": "text", "text": text}],
    }
    if task_id is not None:
        message["taskId"] = task_id
    return message


def build_task(task_id, context_id, state, history, artifacts=None, status_text=None):
    task = {
        "kind": "task",
        "id": task_id,
        "contextId": context_id,
        "status": {
            "state": state,
            "timestamp": utc_now(),
        },
        "history": history,
    }
    if artifacts:
        task["artifacts"] = artifacts
    if status_text:
        task["status"]["message"] = build_message("agent", status_text, context_id, task_id)
    return task

There are two protocol details worth calling out here:

• In A2A 0.3.0, a Message has its own messageId.
• A Task has its own id and a contextId that ties related messages together.

That distinction matters. The JSON-RPC request id, the A2A message id, and the A2A task id are all different things.

Now add discovery and the JSON-RPC router:

@app.route("/.well-known/agent-card.json")
def agent_card():
    return jsonify(AGENT_CARD)


@app.route("/", methods=["POST"])
def jsonrpc():
    body = request.get_json(silent=True)

    if not isinstance(body, dict) or body.get("jsonrpc") != "2.0" or "method" not in body:
        request_id = body.get("id") if isinstance(body, dict) else None
        return jsonrpc_error(request_id, -32600, "Invalid Request")

    method = body["method"]
    request_id = body.get("id")
    params = body.get("params", {})

    if method == "message/send":
        return handle_message_send(request_id, params)
    if method == "tasks/get":
        return handle_tasks_get(request_id, params)
    if method == "tasks/cancel":
        return handle_tasks_cancel(request_id, params)
    return jsonrpc_error(request_id, -32601, f"Method not found: {method}")

This is the first place where a lot of simplified tutorials drift from the spec. message/send is not the whole story. If you're returning task objects, you also need a way to retrieve and manage them. So we'll implement:

• message/send
• tasks/get
• tasks/cancel

Step 3: Handle message/send

Now for the main method:

def handle_message_send(request_id, params):
    if not isinstance(params, dict):
        return jsonrpc_error(request_id, -32602, "params must be an object")

    message = params.get("message")
    if not isinstance(message, dict):
        return jsonrpc_error(request_id, -32602, "params.message is required")
    if message.get("kind") != "message":
        return jsonrpc_error(request_id, -32602, "params.message.kind must be 'message'")
    if not message.get("messageId"):
        return jsonrpc_error(request_id, -32602, "params.message.messageId is required")

    parts = message.get("parts")
    if not isinstance(parts, list) or not parts:
        return jsonrpc_error(request_id, -32602, "params.message.parts must be a non-empty list")

    configuration = params.get("configuration", {})
    if configuration and not isinstance(configuration, dict):
        return jsonrpc_error(request_id, -32602, "params.configuration must be an object")
    if configuration.get("pushNotificationConfig"):
        return jsonrpc_error(
            request_id,
            UNSUPPORTED_OPERATION,
            "Push notifications are not supported by this agent",
        )
    accepted_output_modes = configuration.get("acceptedOutputModes") or []
    if accepted_output_modes and "text/plain" not in accepted_output_modes:
        return jsonrpc_error(
            request_id,
            CONTENT_TYPE_NOT_SUPPORTED,
            "This agent only returns text/plain output",
        )

    text = ""
    for part in parts:
        if isinstance(part, dict) and part.get("kind") == "text":
            text = part.get("text", "").strip()
            if text:
                break
    if not text:
        return jsonrpc_error(request_id, -32602, "No text content in message")

    task_id = str(uuid.uuid4())
    context_id = message.get("contextId") or str(uuid.uuid4())
    normalized_message = deepcopy(message)
    normalized_message["contextId"] = context_id
    history = [normalized_message]

    try:
        result = convert(text)
    except ValueError as exc:
        error_text = str(exc)
        history.append(build_message("agent", error_text, context_id, task_id))
        task = build_task(
            task_id,
            context_id,
            "failed",
            history,
            status_text=error_text,
        )
    else:
        history.append(build_message("agent", result, context_id, task_id))
        task = build_task(
            task_id,
            context_id,
            "completed",
            history,
            artifacts=[
                {
                    "artifactId": str(uuid.uuid4()),
                    "name": "conversion-result",
                    "parts": [{"kind": "text", "text": result}],
                }
            ],
            status_text="Conversion completed.",
        )

    TASKS[task_id] = deepcopy(task)
    return jsonrpc_result(request_id, task)

Three important points:

1. We validate A2A fields, not just JSON-RPC fields.
2. The server generates the task id. The client does not provide it.
3. Application failures return a task with status.state: "failed", not a JSON-RPC error.

That last distinction is important:

• JSON-RPC errors are for protocol or transport problems
• task states are for domain-level outcomes

Step 4: Implement tasks/get and tasks/cancel

Because we store tasks in memory, we can fetch them later:

def handle_tasks_get(request_id, params):
    if not isinstance(params, dict):
        return jsonrpc_error(request_id, -32602, "params must be an object")

    task_id = params.get("id")
    if not task_id:
        return jsonrpc_error(request_id, -32602, "params.id is required")

    task = TASKS.get(task_id)
    if task is None:
        return jsonrpc_error(request_id, TASK_NOT_FOUND, f"Task not found: {task_id}", 404)

    task_copy = deepcopy(task)
    history_length = params.get("historyLength")
    if history_length is not None:
        if not isinstance(history_length, int) or history_length < 0:
            return jsonrpc_error(request_id, -32602, "params.historyLength must be a non-negative integer")
        if history_length > 0:
            task_copy["history"] = task_copy.get("history", [])[-history_length:]

    return jsonrpc_result(request_id, task_copy)

And here's cancel:

def handle_tasks_cancel(request_id, params):
    if not isinstance(params, dict):
        return jsonrpc_error(request_id, -32602, "params must be an object")

    task_id = params.get("id")
    if not task_id:
        return jsonrpc_error(request_id, -32602, "params.id is required")

    task = TASKS.get(task_id)
    if task is None:
        return jsonrpc_error(request_id, TASK_NOT_FOUND, f"Task not found: {task_id}", 404)

    state = task.get("status", {}).get("state")
    if state in TERMINAL_STATES:
        return jsonrpc_error(
            request_id,
            TASK_NOT_CANCELABLE,
            f"Task cannot be canceled from state: {state}",
            409,
        )

    canceled_message = "Task canceled."
    task["status"]["state"] = "canceled"
    task["status"]["timestamp"] = utc_now()
    task["status"]["message"] = build_message("agent", canceled_message, task["contextId"], task["id"])
    task.setdefault("history", []).append(
        build_message("agent", canceled_message, task["contextId"], task["id"])
    )
    TASKS[task_id] = deepcopy(task)
    return jsonrpc_result(request_id, task)

In this toy agent, work completes immediately, so canceling an already finished task returns TaskNotCancelableError (-32002). That's still useful, because it shows how the method behaves even when your agent is synchronous.

Add the small response helpers and startup block:

def jsonrpc_result(request_id, result):
    return jsonify({"jsonrpc": "2.0", "id": request_id, "result": result})


def jsonrpc_error(request_id, code, message, http_status=400):
    return (
        jsonify({
            "jsonrpc": "2.0",
            "id": request_id,
            "error": {"code": code, "message": message},
        }),
        http_status,
    )


if __name__ == "__main__":
    app.run(port=5000, debug=True)

Step 5: The Conversion Logic

This part has nothing to do with A2A. It's just the service our agent happens to provide.

Create converter.py:

import re


UNITS = {
    "temperature": {
        "fahrenheit": {"to_base": lambda f: (f - 32) * 5 / 9, "from_base": lambda c: c * 9 / 5 + 32},
        "celsius": {"to_base": lambda c: c, "from_base": lambda c: c},
        "kelvin": {"to_base": lambda k: k - 273.15, "from_base": lambda c: c + 273.15},
    },
    "distance": {
        "miles": {"to_base": lambda m: m * 1609.344, "from_base": lambda m: m / 1609.344},
        "kilometers": {"to_base": lambda k: k * 1000, "from_base": lambda m: m / 1000},
        "meters": {"to_base": lambda m: m, "from_base": lambda m: m},
        "feet": {"to_base": lambda f: f * 0.3048, "from_base": lambda m: m / 0.3048},
    },
    "weight": {
        "pounds": {"to_base": lambda p: p * 453.592, "from_base": lambda g: g / 453.592},
        "kilograms": {"to_base": lambda k: k * 1000, "from_base": lambda g: g / 1000},
        "ounces": {"to_base": lambda o: o * 28.3495, "from_base": lambda g: g / 28.3495},
        "grams": {"to_base": lambda g: g, "from_base": lambda g: g},
    },
}

ALIASES = {
    "f": "fahrenheit", "°f": "fahrenheit", "fahr": "fahrenheit",
    "c": "celsius", "°c": "celsius",
    "k": "kelvin",
    "mi": "miles", "mile": "miles",
    "km": "kilometers", "kilometer": "kilometers",
    "m": "meters", "meter": "meters",
    "ft": "feet", "foot": "feet",
    "lb": "pounds", "lbs": "pounds", "pound": "pounds",
    "kg": "kilograms", "kilogram": "kilograms",
    "oz": "ounces", "ounce": "ounces",
    "g": "grams", "gram": "grams",
}


def _resolve_unit(name):
    name = name.lower().strip().rstrip(".")
    if name in ALIASES:
        name = ALIASES[name]
    for category, units in UNITS.items():
        if name in units:
            return category, name
    return None, None


def _parse_input(text):
    text = text.strip()
    pattern = r"(?:convert\s+)?(-?\d+(?:\.\d+)?)\s*°?\s*(\w+)\s+(?:to|in)\s+°?\s*(\w+)"
    match = re.search(pattern, text, re.IGNORECASE)

    if not match:
        raise ValueError(
            "Could not parse your request. Try something like: "
            "'Convert 100 Fahrenheit to Celsius'"
        )

    value = float(match.group(1))
    from_unit = match.group(2)
    to_unit = match.group(3)
    return value, from_unit, to_unit


def convert(text):
    value, from_name, to_name = _parse_input(text)

    from_category, from_unit = _resolve_unit(from_name)
    to_category, to_unit = _resolve_unit(to_name)

    if from_category is None:
        raise ValueError(f"Unknown unit: {from_name}")
    if to_category is None:
        raise ValueError(f"Unknown unit: {to_name}")
    if from_category != to_category:
        raise ValueError(
            f"Cannot convert between {from_name} ({from_category}) "
            f"and {to_name} ({to_category})"
        )

    base_value = UNITS[from_category][from_unit]["to_base"](value)
    result = UNITS[from_category][to_unit]["from_base"](base_value)
    return f"{value} {from_unit} = {result:.4g} {to_unit}"

That's it. The protocol layer doesn't care whether this function is regex-based, LLM-based, or a call into another system.

Step 6: Test with curl

Start the server:

python server.py

Fetch the card:

curl http://localhost:5000/.well-known/agent-card.json | python -m json.tool

Now send a valid A2A 0.3.0 request:

curl -X POST http://localhost:5000 \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc": "2.0",
    "id": "req-1",
    "method": "message/send",
    "params": {
      "message": {
        "kind": "message",
        "messageId": "msg-1",
        "contextId": "ctx-1",
        "role": "user",
        "parts": [{"kind": "text", "text": "Convert 100 Fahrenheit to Celsius"}]
      },
      "configuration": {
        "acceptedOutputModes": ["text/plain"]
      }
    }
  }' | python -m json.tool

You should get back a task with:

• kind: "task"
• a server-generated task id
• the request's contextId
• status.state: "completed"
• an artifact containing the conversion result

Save the task id from that response, then fetch it:

curl -X POST http://localhost:5000 \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc": "2.0",
    "id": "req-2",
    "method": "tasks/get",
    "params": {
      "id": "TASK_ID_HERE",
      "historyLength": 1
    }
  }' | python -m json.tool

Try a failure case:

curl -X POST http://localhost:5000 \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc": "2.0",
    "id": "req-3",
    "method": "message/send",
    "params": {
      "message": {
        "kind": "message",
        "messageId": "msg-2",
        "contextId": "ctx-2",
        "role": "user",
        "parts": [{"kind": "text", "text": "Convert 100 miles to celsius"}]
      }
    }
  }' | python -m json.tool

That returns a task with status.state: "failed", because the request was valid A2A even though the conversion itself made no sense.

And if you try to cancel a task that's already finished:

curl -X POST http://localhost:5000 \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc": "2.0",
    "id": "req-4",
    "method": "tasks/cancel",
    "params": {
      "id": "TASK_ID_HERE"
    }
  }' | python -m json.tool

You'll get -32002, TaskNotCancelableError.

Step 7: The Client

Talking to the agent with curl proves the protocol works. Now let's build a client that follows the same discovery-first A2A flow another agent would use.

Create client.py:

import uuid

import requests


def discover(base_url):
    card_url = f"{base_url}/.well-known/agent-card.json"
    response = requests.get(card_url, timeout=10)
    response.raise_for_status()
    return response.json()


def get_jsonrpc_endpoint(card):
    if card.get("preferredTransport") == "JSONRPC":
        return card["url"]

    for interface in card.get("additionalInterfaces", []):
        if interface.get("transport") == "JSONRPC":
            return interface["url"]

    raise ValueError("Agent card does not declare a JSON-RPC endpoint")


def post_jsonrpc(agent_url, payload):
    response = requests.post(agent_url, json=payload, timeout=10)
    try:
        result = response.json()
    except ValueError:
        response.raise_for_status()
        raise

    if response.status_code >= 500:
        response.raise_for_status()
    return result


def send_message(agent_url, text, context_id=None):
    payload = {
        "jsonrpc": "2.0",
        "id": str(uuid.uuid4()),
        "method": "message/send",
        "params": {
            "message": {
                "kind": "message",
                "messageId": str(uuid.uuid4()),
                "contextId": context_id or str(uuid.uuid4()),
                "role": "user",
                "parts": [{"kind": "text", "text": text}],
            },
            "configuration": {
                "acceptedOutputModes": ["text/plain"],
            },
        },
    }
    return post_jsonrpc(agent_url, payload)


def get_task(agent_url, task_id, history_length=None):
    params = {"id": task_id}
    if history_length is not None:
        params["historyLength"] = history_length

    payload = {
        "jsonrpc": "2.0",
        "id": str(uuid.uuid4()),
        "method": "tasks/get",
        "params": params,
    }
    return post_jsonrpc(agent_url, payload)

The important detail here is that the client does not assume the endpoint path. It reads the agent card and chooses the JSON-RPC transport from the card metadata.

Now add a response printer and a simple REPL:

def print_response(result):
    if "error" in result:
        print(f"Error {result['error']['code']}: {result['error']['message']}")
        return

    task = result.get("result", {})
    state = task.get("status", {}).get("state")

    if state == "completed":
        for artifact in task.get("artifacts", []):
            for part in artifact.get("parts", []):
                if part.get("kind") == "text":
                    print(part["text"])
    elif state == "failed":
        status_message = task.get("status", {}).get("message", {})
        for part in status_message.get("parts", []):
            if part.get("kind") == "text":
                print(f"Agent error: {part['text']}")
                return
        print("Agent error: task failed")
    else:
        print(f"Task state: {state}")


def main():
    base_url = "http://localhost:5000"

    print(f"Discovering agent at {base_url}...")
    card = discover(base_url)
    agent_url = get_jsonrpc_endpoint(card)
    print(f"Found: {card['name']} - {card['description']}")
    print(f"Transport: {card['preferredTransport']} -> {agent_url}")
    print(f"Skills: {', '.join(s['name'] for s in card['skills'])}")
    print()

    while True:
        text = input("> ").strip()
        if not text or text.lower() in ("quit", "exit"):
            break

        result = send_message(agent_url, text)
        print_response(result)

        task = result.get("result", {})
        if task.get("id"):
            latest = get_task(agent_url, task["id"], history_length=1)
            print(f"Stored task state: {latest.get('result', {}).get('status', {}).get('state')}")
        print()


if __name__ == "__main__":
    main()

This is still a tiny client, but it's much closer to real A2A behavior:

• it discovers the agent
• it chooses a transport from the card
• it sends a fully shaped message/send request
• it can retrieve task state with tasks/get

The A2A Insight

The interesting thing here is not the converter. It's the shape.

This client could just as easily live inside another agent. If you wrapped it in a server and gave it its own agent card, you'd have an agent that receives a request, discovers another agent, delegates work, and returns the result.

That's agent-to-agent communication in practice. No second protocol. No special "AI-to-AI" channel. Just discovery plus JSON-RPC.

What We Still Didn't Build

Even after tightening this tutorial up for A2A 0.3.0, we're still skipping a lot:

• message/stream for streaming responses
• real long-running tasks
• push notification delivery
• authentication and securitySchemes
• persistent task storage
• richer content types beyond text/plain

But the foundation is now more accurate:

• agent card
• transport metadata
• message/send
• tasks/get
• tasks/cancel
• task ids, message ids, and context ids

That's enough to see what the protocol is doing under the hood.

If you want the finished code, it's on GitHub: waggle-examples/tutorials/a2a-raw-implementation.
